waterchiller Hailea Ultra Titan 1500 (HC500=790Watt cooling capacity)
22.86 € / kuumakse alates
The cooling units from Hailea have been used in trusted waterchillers from other manufacturers for over 15 years. The new heat exchangers of the Ultra series are made from titanium. Therefore the chillers are perfect for watercooling systems. Another positive aspect about the Hailea units is the low noise emission. The pricing of the new series is also pleasantly affordable. New revision: New cool design More robust materials for even longer lifespan Lowered noise emissions Suitable for continuous operation Noise emissions: The small chillers (like HC150) have a noise emission of 20dB(A) only and can be used near the computer / aquarium without disturbing. Bigger models (like HC500) should be additionally decoupled to reduce the noise level if necessary The models HC1000 und HC 2000 should be extra decoupled or maintained in a seperate room. This waterchiller basically replaces the radiator as the coolant is chilled to the desired temperature by this unit. Temperatures down to 4°C are possible, please note that at low temperatures (high temperature difference) condensate may accumulate. Suitable insulation accessories are also available in our shop. Alternatively the coolant temperature can be set to just below room temperature to avoid this problem. Thanks to the low temperatures incredible overclocking potential is available! The lifespan of the components is extended by multiples. This system is also great for no-noise applications as the chiller can be located in another room. We recommend integration of the chiller into the cooling loop in combination with a radiator. This allows use of the chiller when required (overclocking, Benchmarks, summer etc..) and use of the radiator during normal operation. To estimate the required cooling performance here some non-binding estimates. The exact thermal emissions can be requested from the manufacturer of the hardware. CPU: 80W (standard) to 150W (overclocked) GPU: 50W (small cards) to 250W (current models such as GTX 980) MB: 20 to 40W per component The added values of your system must not exceed the given cooling capability of the chiller. What aquarium size can be cooled with my water chiller? The manufacturer provides the following data: Model / aquarium size in liters: HC-130 / 50-100L HC-150 / 50-200L HC-250 / 100-300L HC-300 / 100-400L HC-500 / 200-800L HC-1000 / 300-1000L HC-2000 / 400-1500L We at Aquatuning wish to advise you that the manufacturer’s data was obtained under optimal circumstances. The temperature response of the aquarium may greatly vary because of insulation, heat from lights respectively sunlight. Hence we recommend using the larger model when reaching the upper limit of the aquarium size values. Note regarding shipping: This unit can only be shipped via a forwarding company. As the chipping charges differ by distance an online calculation is not possible. Please provide your full telephone number and E-Mail address when ordering, we will contact you after the order is complete. The shipping charge is approximately 50€ within Germany. Technical specifications: Power: 1/2 PS Power consumption: 375W Cooling capacity: 790W (suitable for extreme OC and cooling) Recommended coolant flow: 1200-3000 l/h Weight: 22kg Cooling agent: R134A Dimensions: 475x360x490mm (LxWxH) Connector outside diameter: 20-22mm Heat exchanger material: Titanium max. compressive load: 0,8bar Temperature adjustments: Digital read-out (precision 0,1°C), temperature setting in 1°C steps current demand: 2.4 A (50 Hz) current drain: 552 W Scope of Delivery 1x Waterchiller Hailea Ultra Titan 1500 2x 90° angle with rubber seal 2x straight with rubber seal 2x suitable hose clamps Note for first-time users: If you should have problems with your chiller please contact us before returning the chiller to us. In most cases there is no actual problem with the chiller, but the functionality of the unit is not fully understood by the user yet. Please note the following: The compressor unit automatically switches itself on and off, if the temperature sensor is manipulated your warranty is void, the noise level or an allegedly not sufficient cooling performance are no reason for a reclamation. The chiller can only function properly if the cooling loop is equipped with a sufficiently powerful pump. If these facts are considered most reclamations can be avoided and you will greatly enjoy this product! Note for aquarium-use: The cooling performance is affected by the aquarium-lamp the reduced pump power due to filters and the thermal waste of the pump. We therefore recommend to order the ciller at least on power-lever higher that theoretically calculated This product has been reviewed for you (by): Overclockingstation Zockon bit-tech (engl.) How2 (Userreview): Hardwareluxx
