UNI-T LM320F Protractor Angle Finder
UNI-T
Product code: LM320F
Price
45.60 €
Uni-T LM320F Angle Finder
The Uni-T LM320F Angle Finder is the most advanced model in the series, designed for more demanding assembly and installation applications. It offers a 4×90° measurement range and three laser lines, making it easy to precisely mark reference points. The four-sided magnetic base allows for convenient mounting in various positions, and support for multiple units and measurement modes enhances the device’s functionality. The backlit screen and compact design improve user comfort, while the built-in rechargeable battery ensures mobility and convenience.
Included
Angle measurerUSB-C cableUser manual
Specifications
| Manufacturer | Uni-T |
|---|---|
| Model | LM320F |
| Type | Angle measurer with laser |
| Measurement range | 4 × 90° |
| Resolution | ±0.05° |
| Accuracy | ±0.2° |
| Repeatability | ±0.2° |
| Units | °, %, mm/m, in/ft |
| Laser lines | 3 |
| Operating time | Up to 6 h |
| Functions | Relative and absolute measurement, Data Hold, automatic screen rotation, backlight |
| Base | Four-sided magnetic |
| Power supply | 1000 mAh rechargeable battery |
| Dimensions | 83.5 x 70 x 35.5 mm |
| Weight | 180 g |
| Certifications | CE, RoHS |
