ASUS Prime AP201 MicroATX Mini Tower Black
ASUS
Product code: 90DC00G0-B39000
- CPU<: 170 mm
- GPU<: 338 mm
- Colour: Black
- Case form: microATX
Price
90.60 €
Monthly payment
7.00 € / starting from monthly
The ASUS Prime AP201 is a stylish 33-liter MicroATX case with tool-free side panels and a quasi-filter mesh, with support for 360 mm coolers, graphics cards up to 338 mm long, and standard ATX PSUs. - Quasi-Filter Mesh Panels: A mesh design comprised of over 57,000 precision-machined 1.5mm holes increases airflow and provides a compelling view of the components within your build.
- Optimized for Cooling: With support for 280 and 360mm radiators and up to six fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware.
- Industry-Leading Spatial Efficiency: Despite a 33L footprint, the AP201 supports ATX PSUs up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling, and various storage devices.
- Tool-Free Side Panels: A simple yet secure clip mechanism allows chassis side panels to be easily removed and resistant to accidental dislodging.
- Sizeable Cable-Management: The AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap to tuck cables out of sight.
- Front Panel USB Type-C® Support: The front panel of the AP201 features a USB 3.2 Gen 2 Type-C port, so users can enjoy transfer speeds of up to 10 Gbps.
- Optimized for Cooling: With support for 280 and 360mm radiators and up to six fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware.
- Industry-Leading Spatial Efficiency: Despite a 33L footprint, the AP201 supports ATX PSUs up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling, and various storage devices.
- Tool-Free Side Panels: A simple yet secure clip mechanism allows chassis side panels to be easily removed and resistant to accidental dislodging.
- Sizeable Cable-Management: The AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap to tuck cables out of sight.
- Front Panel USB Type-C® Support: The front panel of the AP201 features a USB 3.2 Gen 2 Type-C port, so users can enjoy transfer speeds of up to 10 Gbps.
Technical Details
Dimensions205 x 350 x 460 mm
Form FactorMicro ATX; Mini ITX
mATX supportYes
Mini-ITX supportMiniITX
GPU length up to338 mm
CPU cooler height up to170 mm
PSU supported18 cm
Weight5.8 kg
Height460 mm
Width205 mm
Depth350 mm
ColourBlack
Connectivity
I/O2 x USB 3.2 Gen1; 1x microphone; 1 x headphones; 1 x UB1 x USB 3.2 Gen 2 Type-CavS 3.2 Gen 2 Type-C
Headphone out1x 3.5mm kõrvaklapi pesa
Microphone in1
USB 3.22x USB 3.2 A TÜÜP
Drive Bays
2.5"1x 2.5" pesa
2.5"/3.5"3x 3.5" pesa
3.5"3
Fan support
Fan CompatabilityTop: 3 x 120 mm; 2 x 140 mm, Rear: 1 x 120 mm, Pre-installed Fans (Rear): 1 x 120 mm
Top installed3x 120 mm, 2x 140 mm
Rear installed1x 120 mm
Rear maximum2; 120
Product can only be ordered
Product is not currently available in stores.
Available to order:
Ordering to a store 4-8 working days.21 pcs
